1000 Membrane

HOME > PRODUCTS > Filter presses > Membrane filter press > 1000 Membrane

1000 Membrane (16bar) (cloth washer)
浏览次数：
  • 1000 Membrane (16bar) (cloth washer)

技术规格 资料下载





XG1000 Membrane (cloth washer) (16bar)
Filter pressure≤1.2MpaFilter chamber depth before the squeeze40mmCloth washing rack moving motor power0.75kw
Membrane squeezing pressure≤1.6MpaMain oil pump motor power4kwCylinder diameterD280mm
Cylinder pressure when plates closing≤20MpaMotor power of
bombay doors oil pump		1.5kwMaximum stroke of oil cylinder750mm
Chamber plate size1000*1000*68Plate shifter motor power0.55kw

Diaphragm plate size1000*1000*72Cloth washing rack up and down motor power1.1kw



ModelFilter area (㎡)Number of diaphragm plates (pieces)Number of chamber plates (pieces）Number of filter chambers (pieces)Foot center distance L1(mm)Overall size L*W*H（mm）Filter chamber volume before squeezing (L)Total weight（kg）
XG100JYZ16Z3F1Q1-32U32109203109 4166*2132*40326405321
XG100JYZ16Z3F1Q1-40U401211243393 4450*2132*40328005539
XG100JYZ16Z3F1Q1-50U501514303819 4876*2132*403210005866
XG100JYZ16Z3F1Q1-60U601817364245 5302*2132*403212006193
XG100JYZ16Z3F1Q1-70U702120424671 5728*2132*403214006520
XG100JYZ16Z3F1Q1-80U802423485097 6154*2132*403216006847
XG100JYZ16Z3F1Q1-90U902726545523 6580*2132*403218007174
XG100JYZ16Z3F1Q1-100U1003029605949 7006*2132*403220007501
XG100JYZ16Z3F1Q1-110U1103332666375 7432*2132*403222007828
XG100JYZ16Z3F1Q1-120U1203635726801 7858*2132*403224008155
