1250 Membrane (16bar) (cloth washer)
浏览次数：
  • 1250 Membrane (16bar) (cloth washer)

技术规格 资料下载





XG1250 Membrane (cloth washer) (16bar)
Filter pressure≤1.2MpaFilter chamber depth before the squeeze40mmCloth washing rack moving motor
 power		0.75kw
Membrane squeezing pressure≤1.6MpaMain oil pump motor power5.5kwCylinder diameterD360mm
Cylinder pressure when plates closing≤20MpaPlate shifter motor power0.75kwMaximum stroke of oil cylinder1000mm
Chamber plate size1250*1250*70Motor power of bombay doors oil pump1.5kw

Diaphragm plate size1250*1250*78Cloth washing rack up and down motor power1.1kw



ModelFilter area（㎡）Number of filter chambers (pieces)Number of diaphragm plates (pieces)Number of chamber plates (pieces)Foot center distance L1(mm)Filter chamber volume before squeezing (L)Overall size L*W*H（mm）Total weight（kg）
XG125JYZ16Z3F1Q1-100U100381918472020005798*1956*17459200
XG125JYZ16Z3F1Q1-120U112422120502022406098*1956*17459500
XG125JYZ16Z3F1Q1-120U120462322532024006398*1956*17459900
XG125JYZ16Z3F1Q1-125U125482423547025006548*1956*174510000
XG125JYZ16Z3F1Q1-140U140542726592028006998*1956*174510500
XG125JYZ16Z3F1Q1-150U150582928622030007298*1956*174510800
XG125JYZ16Z3F1Q1-160U160623130652032007598*1956*174511200
XG125JYZ16Z3F1Q1-180U180683433697036008048*1956*174511700
XG125JYZ16Z3F1Q1-200U200763837757040008648*1956*174512300
XG125JYZ16Z3F1Q1-224U224864342832044809398*1956*174513100
XG125JYZ16Z3F1Q1-250U2509648479070500010148*1956*174514000
